Part V

Virtual Private Network

D-Link 132

Configuring the IPSec IKE tunnels

For the main office (the hub), we have to create the IKE tunnels, and then create VPN hub and add tunnels to it as members.

For the VPN settings, please refer to

Chapter 13 for details. Use the information in the following Table 15-1 to configure IKE

tunnels. After finishing the IPSec VPN setting, please remember to add a WAN-to-LAN firewall rule.

Field Name Main Office Information Branch_1 Information Branch_2 Information

Status

Active Enable Enable Enable Enable

IKE Rule Name IKEVpnA IKEVpnB IKEMainVPN IKEMainVPN

Condition

Local Address Type Subnet Address Subnet Address Subnet Address Subnet Address

IP Address 192.168.1.0 192.168.1.0 192.168.40.0 192.168.88.0

PrefixLen/Subnet Mask 255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0

Remote Address Type Subnet Address Subnet Address Subnet Address Subnet Address

IP Address 192.168.40.0 192.168.88.0 192.168.1.0 192.168.1.0

PrefixLen/Subnet Mask 255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0

Action

Negotiation Mode Main Main Main Main

Encapsulation Mode Tunnel Tunnel Tunnel Tunnel

Outgoing Interface WAN1 WAN1 WAN1 WAN1

Peer’s IP Address 210.2.1.1 210.2.1.2 61.2.1.1 61.2.1.1

My Identifier IP Address IP Address IP Address IP Address

Peer’s Identifier IP Address IP Address IP Address IP Address

ESP Algorithm Encrypt and

Authenticate (DES,

MD5)

Encrypt and

Authenticate (DES,

MD5)

Encrypt and

Authenticate (DES,

MD5)

Encrypt and

Authenticate (DES,

MD5)

AH Algorithm Not selected Not selected Not selected Not selected

Pre-Shared Key 1234567890 1234567890 1234567890 1234567890

Table 15-1 The IKE tunnel configuration
