D-Link DWC-1000 User Manual 109

Section 4 - Advanced WLAN Conguration

2. Click Add New WDS Manage AP.

3. Complete the elds in the table below and click Save.

Field Description

WDS Managed Group ID

Select the ID associated with the group to congure.

Valid AP MAC Address MACAddressoftheAP.

Hardware Type String SelecttheAPfromthedrop-downmenu.

WDS AP MAC Address EntertheWDSAPMACaddress.

STP Priority

SpanningTreePriorityforthisAP.TheSTPpriorityisusedonlywhenspanningtreemode

is enabled.

TheSTPprioritydetermineswhichAPisselectedastherootofthespanningtreeand

whichAPhaspreferenceoveranotherAPwhenmultipleequalcostpathsexistinthe

topology.ThelowervalueforthespanningtreeprioritymeansthattheAPismorelikely

to be used for bridging data into the campus network. You should assign a lower priority

totheAPsconnectedtothewirednetworkthantothesatelliteAPs.

TheSTPpriorityvalueisroundeddowntoamultipleof4096.Therangeis0–61440,and

the default value is 36864.
