Section 5 - Advanced Network Conguration

RIP

Dynamic routing using the Routing Information Protocol (RIP) is an Interior Gateway Protocol (IGP) that is

common in LANs.With RIP this controller can exchange routing information with other supported routers/

controllers in the LAN and allow for dynamic adjustment of routing tables in order to adapt to modications in

theLANwithoutinterruptingtracow.

Path:Network>Routing>RIP

TocongureRIP:

1. Click Network > Routing > RIP.

2. Complete the elds in the table below and click Save.

Field Description

Direction

The RIPdirection will dene howthis controllersends and receivesRIP packets. Select one of the

following:

• Both:ThecontrollerbothbroadcastsitsroutingtableandalsoprocessesRIPinformationreceived

fromothercontrollers.ThisistherecommendedsettinginordertofullyutilizeRIPcapabilities.

• Out Only: The controller broadcasts its routing table periodically but does not accept RIP

information from other controllers.

• In Only:ThecontrolleracceptsRIPinformationfromothercontrollers,butdoesnotbroadcastits

routing table.

• None:ThecontrollerneitherbroadcastsitsroutetablenordoesitacceptanyRIPpacketsfrom

othercontrollers.ThiseectivelydisablesRIP.

Version

TheRIPversionisdependentontheRIPsupportofotherroutingdevicesintheLAN.

• Disabled:ThisisthesettingwhenRIPisdisabled.

• RIP-1: A class-based routing version that does not include subnet information. This is the most

commonly supported version.

• RIP-2:IncludesallthefunctionalityofRIPv1plusitsupportssubnetinformation.Thoughthedata

issentinRIP-2formatforbothRIP-2BandRIP-2M,themodeinwhichpacketsaresentisdierent.

RIP-2BbroadcastsdataintheentiresubnetwhileRIP-2Msendsdatatomulticastaddresses.

 Note:IfRIP-2BorRIP-2Mistheselectedversion,authenticationbetweenthiscontrollerandother

controllers(conguredwiththesameRIPversion)isrequired.MD5authenticationisusedina

rst/second key exchange process. The authentication key validity lifetimes are congurable to

ensure that the routing information exchange is with current and supported controllers detected

on the LAN.

Save Click Save to save your settings.
