D-Link DWC-1000 User Manual 366
Appendix B - Factory Default Settings
Appendix B - Factory Default Settings
Feature Description Default Setting
Device Login
UserloginURL http://192.168.10.1
Username(casesensitive)
admin
Loginpassword(casesensitive)
admin
Local area network
(LAN)
IPaddress 192.168.10.1
IPv4subnetmask 255.255.255.0
DHCPserver Disabled
DHCPstartingIPaddress 192.168.10.100
DHCPendingIPaddress 192.168.10.254
Time zone GMT
Time zone adjusted for Daylight Savings Time
Disabled
SNMP Disabled
Remotemanagement Disabled
