PPTP VPN

Server

Path:VPN>PPTPVPN>Server

APPTPVPNcanbeestablishedthroughthisswitch.OnceenabledaPPTPserverisavailableontheswitchfor

LANandWANPPTPclientuserstoaccess.OncethePPTPserverisenabled,PPTPclientsthatarewithintherange

ofconguredIPaddressesofallowedclientscanreachthecontroller’sPPTPserver.Onceauthenticatedbythe

PPTPserver(thetunnelendpoint),PPTPclientshaveaccesstothenetworkmanagedbythecontroller.

TherangeofIPaddressesallocatedtoPPTPclientscancoincidewiththeLANsubnet.AswellthePPTPserver

willdefaulttolocalPPTPuserauthentication,butcanbeconguredtoemployanexternalauthenticationserver

should one be congured.

Field Description

Enable PPTP Server Select either IPv4 or IPv6.

PPTP Routing Mode Select either NAT or Classical.

Starting/Ending IP Address EntertheIPaddressrangetoassignyourPPTPclients.

IPv6 Prex IfyouselectedIPv6,entertheIPv6prex.

IPv6 Prex Length IfyouselectedIPv6,entertheIPv6prexlength.

Authentication Select the authentication type from the drop-down menu.

Authentication Supported Toggle which type of authentication you want to enable to ON.

Idle TimeOut Entertheamountoftimeinsecondsthattheconnectionwilldisconnectwhenidle.

NetBIOS Toggle to ONtoallowNetBIOSbroadcaststotravelovertheVPNtunnel.

Save Click to save your settings.

TocreateaPPTPVPNserver:

1. Click VPN > PPTP VPN > Server.

2. Complete the elds in the table below and click Save.
