D-Link DWC-1000 User Manual 322
Section 9 - Maintenance
Set Login Session Timeout
Path:Maintenance>Administration>SessionSettings
EnterthesessiontimeoutvalueforadministratorandguestusersandthenclickSave.
Set USB Share Ports
Path:Maintenance>Administration>USBSharePorts
EnableUSBportsharingonUSBport1,2,orbothandclickSave.
