D-Link DWC-1000 User Manual 295

Section 8 - Viewing Status and Statistics

Path:Status>WirelessInformation>AccessPoint>AllAPs

TheAllAPsListpageshowssummaryinformationaboutmanaged,failed,androgueaccesspointsthewireless

controller has discovered or detected. Status entries can be deleted manually.

All APs

Field Description

MAC Address MACaddressoftheaccesspoint.

IP Address IPaddressoftheaccesspoint.

Age

Amount of time that has passed since the access point was last detected and

the information was last updated.

Status

Accesspointstatus.Possiblevaluesare:

• Managed =accesspointprole conguration hasbeen applied tothe

access point and the access point is operating in managed mode.

• NoDatabaseEntry=accesspoint’sMACaddressdoesnotappearinthe

localorRADIUSValidAPdatabase.

• Authentication(FailedAP)=accesspointfailedtobeauthenticatedby

thewirelesscontrollerorRADIUSserver.

• Failed = wireless controller lost contact with the accesspoint. A failed

entrywillremainintheManagedAPdatabaseunlessyouremoveit.Note:

a managed access point shows a failed status temporarily during a reset.

• Rogue=accesspointhasnottriedtocontactthewirelesscontrollerand

theaccesspoint’sMACaddressisnotintheValidAPdatabase.

Radio Wireless radio mode the access point is using.

Channel Operating channel for the radio.
