D-Link DWC-1000 User Manual 258

Section 7 - VPN

L2TP VPN

Server

Path:VPN>L2TPVPN>Server

AL2TPVPNcanbeestablishedthroughthisswitch.OnceenabledaL2TPserverisavailableontheswitchforLAN

andWANL2TPclientuserstoaccess.OncetheL2TPserverisenabled,PPTPclientsthatarewithintherangeof

conguredIPaddressesofallowedclientscanreachthecontroller’sL2TPserver.OnceauthenticatedbytheL2TP

server(thetunnelendpoint),L2TPclientshaveaccesstothenetworkmanagedbytheswitch.

TherangeofIPaddressesallocatedtoL2TPclientscancoincidewiththeLANsubnet.AswelltheL2TPserver

willdefaulttolocalL2TPuserauthentication,butcanbeconguredtoemployanexternalauthenticationserver

should one be congured.

Field Description

Enable L2TP Server Select either IPv4 or IPv6.

L2TP Routing Mode Select either NAT or Classical.

Starting/Ending IP Address EntertheIPaddressrangetoassignyourL2TPclients.

IPv6 Prex IfyouselectedIPv6,entertheIPv6prex.

IPv6 Prex Length IfyouselectedIPv6,entertheIPv6prexlength.

Authentication Select the authentication type from the drop-down menu.

Authentication Supported Toggle which type of authentication you want to enable to ON.

Idle TimeOut Entertheamountoftimeinsecondsthattheconnectionwilldisconnectwhenidle.

NetBIOS Toggle to ONtoallowNetBIOSbroadcaststotravelovertheVPNtunnel.

Save Click to save your settings.

TocreateaL2TPVPNserver:

1. Click VPN > L2TP VPN > Server.

2. Complete the elds in the table below and click Save.
