D-Link DWC-1000 User Manual 114

Section 4 - Advanced WLAN Conguration

Field Description

Server Address

EntertheIPaddressofthehostwheretheupgradeleislocated.Thehostmusthave

aTFTPserverinstalledandrunning.

File Path

EnterthelepathontheTFTPserverwherethesoftwareislocated.Youmayenterup

to 96 characters.

File Name

Enterthenameoftheupgradele.Youmayenterupto32characters,andthele

extension .tar must be included.

Group Size

WhenyouupgrademultipleAPs,eachAPcontactstheTFTPservertodownloadthe

upgradele.To prevent theTFTP serverfrombeingoverloaded,you canlimit the

numberofAPstobeupgradedatatime.

IntheGroupSizeeld,enterthenumberofAPsthatcanbeupgradedatthesame

time. When one group completes the upgrade, the next group begins the process.

Image Download Type

Type of the image to be downloaded, which can be one of the following:

• AllImages

• DWL-8600AP

• DWL-3600AP/DWL-6600AP

• DWL-2600AP

• DWL-8610AP

Note: To download all images, make sure you specify the le path and le name for

bothimagesintheappropriateFilePathandFileNameelds.

Managed AP

ThelistshowsalltheAPsthatthecontrollermanages.IfthecontrolleristheCluster

Controller,thenthelistshowstheAPsmanagedbyallcontrollersinthecluster.

EachAPisidentiedbyitsMACaddress,IPaddress,andLocationinthe<MAC‐IP‐

Location>format.ToupgradeasingleAP,selecttheAPMACaddressfromthedrop

downlist.ToupgradeallAPs,selectAllfromthetopofthelist.IfAllisselected,the

GroupSizeeldwilllimitthenumberofsimultaneousAPupgradesinordernotto

overwhelmtheTFTPserver.ToselectmultipleAPstoupgrade,CTRL+clicktheAPs

to upgrade.

Note:D‐LinkrecommendsthatyouupgradeallmanagedAPsatthesametime.
