Open VPN

VPN>OpenVPN>Settings

OpenVPN allows peers to authenticate each other using a pre-shared secret key, certicates, or username/

password. When used in a multiclient-server conguration, it allows the server to release an authentication

certicateforeveryclient,usingsignatureandCerticateauthority.AnOpenVPNcanbeestablishedthrough

this controller.

You can select server mode, client mode, or access server client mode. In access server client mode, the user has

todownloadtheautologinprolefromtheOpenVPNAccessServeranduploadthesametoconnect.

Server

Settings

Field Description

Mode Select Server.

VPN Network EntertheIPnetworkfortheVPN.

VPN Netmask Enterthenetmask.

Port Enterwhatporttouse.Thedefaultportis1194.

Tunnel Protocol Select either TCP or UDP.

Encryption Algorithm Select the encryption algorithm from the drop-down menu.

Hash Algorithm Select the hash algorithm from the drop-down menu.

Tunnel Type

Select either Full Tunnel or Split Tunnel.FullTunnelmodejustsendsalltracfromtheclientacrossthe

VPNtunneltothecontroller.SplitTunnelmodeonlysendstractotheprivateLANbasedonpre-specied

clientroutes.IfyouselectSplitTunnel,referto“LANConguration”onpage119tocreatelocalnetworks.

Save Click Save to save and activate your settings.

TocongurethecontrollerasanOpenVPNServer:

1. Click VPN > OpenVPN > Settings.

2. Toggle OpenVPN to ON and complete the elds in the table below.
