Section 4 - Advanced WLAN Conguration

Field Description

MAC Address MACaddressoftheaccesspoint.

AP Mode

Select standalone, managed, or rogue. Selecting standalone or managed will require

youtollouttheelds(refertothenextpage).

• Standalone

• Managed=accesspointprolecongurationhasbeenappliedtotheaccess

point and the access point operating in managed mode.

• Rogue=accesspointhasnottriedtocontactthewirelesscontrollerandthe

accesspoint’sMACaddressisnotintheValidAPdatabase.

Location Optional eld to identify location of the access point being managed.

Expected SSID

IfAPMode=Standalone,theSSIDthattheaccesspointshouldbesetto.Thisisfor

reference only.

Expected Channel

IfAPMode=Standalone,thechanneltobeusedforwirelesscommunication.Thisis

for reference only.

Expected WDS Mode

IfAPMode=Standalone,theWDS(WirelessDistributedSystem)modetobeusedif

you intend to use WDS. This is for reference only.

Expected Security Mode IfAPMode=Standalone,thesecuritymodetobeused.Thisisforreferenceonly.

Expected Wired Network Mode

IfAPMode=Standalone,selectwhetherwirednetworkingisgoingtobeallowed.

This is for reference only.

Authentication Password IfAPMode=Managed,turnontorequireapasswordforauthentication.

Prole IfAPMode=Managed,selectaproletoapplyforAPconguration.

Radio

IfAPMode=Managed,thisisWirelessradiomodethattheaccesspointisusing.The

eldsbelowappearafteryouhaveselectedManagedAPMode.

Channel IfAPMode=Managed,thisisoperatingchannelfortheradio.

Power IfAPMode=Managed,thisispercentageofpowertousefortheradio.

ManagedMode

StandaloneMode

RogueMode
