D-Link DWC-1000 [297/368] Button description

D-Link DWC-1000 User Manual 297

Section 8 - Viewing Status and Statistics

Button Description

AP Details Shows detailed status information collected from the access point.

Radio Details Shows detailed status for a radio interface.

Neighbor APs

ShowstheneighborAPsthatthespeciedAPhasdiscoveredthroughperiodic

RFscansontheselectedradiointerface.

Neighbor Clients

Shows information about wireless clients associated with an access point or

detected by the access point radio.

VAP Details

Showssummary information about the virtual accesspoints(VAPs)forthe

selected access point and the access point radio interface that the wireless

controller manages.

Distributed Tunnel Shows information about the L2 tunnels currently in use on the access point.

Reset AP ResetthemanagedAPbacktothefactorydefaultsettings.

Disassociate Clients ViewdisassociateclientswiththeselectedAP.

The Managed AP Statistics page shows information about trac on the access point’s wired and wireless

interfaces. This information can help diagnose network issues, such as throughput problems. To view the

statisticsforamanagedaccesspoint,right-clickonitsentryintheManagedAPListandselectAP Statistics,

Radio Statistics, and VAP Statistics.

Button Description

AP Statistics

Shows the number and type of packets transmitted and received on a specic

access point.

Radio Statistics

Shows per-radio information about the number and type of packets

transmitted and received for a specic access point.

VAP Statistics

Shows per-VAP information about the number of packets transmitted and

received and the number of wireless client failures for a specic access point.
