Section 5 - Advanced Network Conguration

Congure Flow-based Control

Path:Network>QoS>LANQoSPolicy>FlowControl

TheFlow-BasedQoSPolicyallowsyoutolimittheBandwidthforaparticularservice.Changeshereaectthe

tracofaconguredservicethatisegressedontheports.

1. Go to Network > QoS > LAN QoS Policy > Flow Control tab.

2. Click Add New Flow-based Control QoS.

Field Description

Prole Name The name of the prole.

Service

Select the type of service you want to use. The choices are:

Any, aim, bgp, bootp_client, bootp_server, cu-seeme udp, cu-seeme tcp, dns udp,

dns tcp, nger, ftp, http, https, icmp, icq, imap2, imap3, irc, news, nfs, nntp, ping,

pop3, pptp, rcmd, rea-audio, rexec, rlogin, rtelnet, rtsp tcp, rtsp udp, sftp, smtp, snmp

tcp, snmp udp, snmp-traps tcp, snmp-traps udp, sql-net, ssh tcp, ssh udp, strmworks,

tacacs, telnet, tftp, rip, kie, shttpd, ipsec-udp-encap, ident, vddolive, ssh, sip-tcp, sip-

udp, or icmpv6.

Source IP Address ThesourceIPaddress

Destination IP Address ThedestinationIPaddress

Bandwidth Limit the Bandwidth for a particular service.

3. Complete the elds in the table below and click Save.
