D-Link DWC-1000 User Manual 256

Section 7 - VPN

Client

Path:VPN>PPTPVPN>Client

PPTPVPNClientcanbeconguredonthisswitch.Usingthisclientyoucanaccessremotenetworkwhichis

localtoPPTPserver.Onceclientisenabled,theusercanaccessStatus>ActiveVPNspageandestablishPPTP

VPNtunnelclickingConnect.

Field Description

Client Toggle to ONtoenablePPTPclient.

Server IP EntertheIPaddressofthePPTPserveryouwanttoconnectto.

Remote Network Entertheremotenetworkaddress.ThisaddressislocalforthePPTPServer.

Remote Netmask Entertheremotenetworksubnetmask.

Username EnteryourPPTPusername.

Password EnteryourPPTPpassword.

MPPE Encryption ToggletoONtoenableMicrosoftPoint-to-PointEncryption(MPPE).

Idle Time Out Entertheamountoftime(inseconds)thatyouwilldisconnectfromthePPTPserverwhenidle.

Save Click Save to save and activate your settings.

ToconguretheswitchasaPPTPVPNclient:

1. Click VPN > PPTP VPN > Client tab.

2. Toggle Client to ON and complete the elds in the table below.
