D-Link DWC-1000 User Manual 210
Section 6 - Securing Your Network
Field Description
Payment Processor Selectthepaymentagent(Authorize.net).
Paypal
Login ID EntertheAPIaccountIDusedforreceivingpayments.
Transaction Key Enteryourtransactionkey.
MD5 Hash EnteryourMD5Hashvalue.
Transaction Server Live is selected.
Transaction Mode Select Live or Test.
Currency Select the currency type.
