D-Link DWC-1000 User Manual 163

Section 5 - Advanced Network Conguration

Field Description

Route Name

Enterauniquenameforthisstaticroute.Thenameshouldallowyoutoeasilyidentify

this static route from others you may add.

Active

Activates or deactivates the status route. Choices are:

• ON=activatestaticroute.

• OFF=deactivatestaticroute.

Private

Designates the static route as private. Choices are:

• ON=staticrouteisprivate.

• OFF=staticrouteisnotprivate.

Destination IP Address EntertheIPaddressofthestaticroute’sdestination.

IP Subnet Mask Enterthesubnetmaskofthestaticroute.

Interface

Select the wireless controller interface that will interface to the static route. Choices are:

• Option1/Option2:Thewirelesscontroller’sOptionportwillinterfacetothestatic

route.

• LAN>VLAN:Thewirelesscontroller’sLANorVLANportwillinterfacetothestatic

route.

• DMZ:TheportconguredforDMZwillinterfacetothestaticroute.

Gateway IP Address

EntertheIPaddressofthegatewayrouter,whichisthenexthopaddressforthewireless

controller.

Metric Entertheadministrativedistanceoftheroute.
