Protocol Binding

Path:Network>Routing>ProtocolBinding

ProtocolbindingsareusefulwhentheLoadBalancingfeatureisinuse.Selectingfromalistofconguredservices

oranyoftheuser-denedservices,thetypeoftraccanbeassignedtogooveronlyoneoftheavailableOption

ports. For increased exibility the source network or machines can be specied as well as the destination network

ormachines.Forexample,theVOIPtracforasetofLANIPaddressescanbeassignedtooneOptionandany

VOIPtracfromtheremainingIPaddressescanbeassignedtotheotherOptionlink.Protocolbindingsareonly

applicable when load balancing mode is enabled and more than one Option port is congured.

To add, edit, or delete a protocol binding entry:

1. Click Network > Routing > Protocol Binding.

2. Right-clickacurrententryandselectEdit or Delete. To add a new entry, click Add New Protocol Binding.

3. Complete the elds in the table below and click Save.

Field Description

Service Select a service from the drop-down menu.

Local Gateway Select an Option interface.

Source Network

Select the source network: Any, Single Address, or Address Range. If Single Address or Address

Rangeisselected,entertheIPaddressorIPrange.

Destination Network

Select the destination network: Any, Single Address, or Address Range. If Single Address or

AddressRangeisselected,entertheIPaddressorIPrange.

Save Click Save to save your settings.
