D-Link DWC-1000 User Manual 250
Section 7 - VPN
DHCP Range
To congure the DHCP over IPSecDHCPserversettings:
1. Click VPN > IPSec VPN > DHCP Range.
2. Complete the elds in the table below and click Save.
Field Description
Starting IP Address EnterthestartingIPaddresstoissueyourclientsconnectingusingDHCPoverIPSec.
Ending IP Address EntertheendingIPaddress.
Subnet Mask Enterthesubnetmask.
Save Click Save to save and activate your settings.
ThispagedisplaystheIPrangetobeassignedtoclientsconnectingusingDHCPoverIPSec.Bydefaulttherange
is in 192.168.12.0 subnet.
