D-Link DWC-1000 User Manual 293

Section 8 - Viewing Status and Statistics

Global Status

Path:Status>WirelessInformation>AccessPoint>GlobalStatus

TheAPGlobalStatuspageshowssummaryinformationaboutmanaged,failed,androgueaccesspointsthe

wireless controller has discovered or detected.

Viewing Access Point Information

Field Description

Total APs

TotalnumberofManagedAPsinthedatabase.Thisvalueisalwaysequalto

the sum of Managed Access Points, Connection Failed Access Points, and

DiscoveredAccessPoints.

Managed APs

Number of APs in the managed AP database that are authenticated,

congured, and have an active connection with the Wireless controller.

Standalone APs

NumberoftrustedAPsinStandalonemode.APsinStandalonemodearenot

managed by a controller.

Rogue APs

NumberofRogueAPscurrentlydetectedontheWLAN.WhenanAPperforms

an RF scan, it might detect access points that have not been validated. It

reportstheseAPsasrogues.

Discovered APs

APsthathaveaconnectionwiththecontroller,buthaven’tbeencompletely

congured. This value includes all managed APs with a Discovered or

Authenticated status.

Connection Failed APs

Number of APs that were previously authenticated and managed, but

currently don’t have connection with the Wireless controller.

Authentication Failed APs

Number of APs that failed to establish communication with the FASTPATH

Unied Wireless controller.
