D-Link DWC-1000 User Manual 160

Section 5 - Advanced Network Conguration

Double VLANs

Path:Network>VLAN>AdvancedVLAN>DoubleVLAN

DoubleVLANTunnelingallowstheuseofasecondtagonnetworktrac.Theadditionaltaghelpsdierentiate

between customers in the Metropolitan Area Networks (MAN) while preserving individual customer’sVLAN

identicationwhentheyentertheirown802.1Qdomain.

Withtheintroductionofthissecondtag,youdonotneedtodividethe4kVLANIDspacetosendtraconan

Ethernet‐basedMAN.

With Double VLAN Tunneling enabled, every frame that is transmitted from an interface has a DVlan Tag attached

whileeverypacketthatisreceivedfromaninterfacehasatagremoved(ifoneormoretagsarepresent).

Use the Double VLAN Tunneling page to congure Double VLAN frame tagging on one or more ports.

1. Go to Network > VLAN > Advanced VLAN > Double VLAN tab.

2. Click Add New Double VLAN.

3. SelecttheEtherType:Dot1q, VLAN, or Custom Tag.

4. Click Save.

3. Complete the elds in the table below and click Save.

Field Description

VLAN ID SpecifytheVLANIDtoassociatewiththisgroup.Therangeis1‐3965.

Group ID Identies the group to congure.

Group Name

(Optional)EnterormodifyanametoassociatewithprotocolgroupID.Thenamecan

be up to 16 characters.

Interface Selectstheinterface(s)toaddorremovefromthisgroup.

Protocol List Specify one or more protocols to associate with this group.
