Section 7 - VPN Settings

Tunnel Mode

Path:VPN>IPSecVPN>TunnelMode

Whentunnelmodeisselected,youcanenableNetBIOSandDHCPoverIPSec.DHCPoverIPSecallowsthisswitch

toserveIPleasestohostsontheremoteLAN.YoucanalsodeneasingleIPaddress,arangeofIPs,orasubnet

on both the local and remote private networks that can communicate over the tunnel.

TheDWC-1000allowsfulltunnelandsplittunnelsupport.Fulltunnelmodejustsendsalltracfromtheclient

across theVPN tunnel to the switch. Split tunnel mode only sends trac to the private LAN based on pre-

Start/End IP Address EnterthestartingandendingIPaddresses.

Primary/Secondary DNS EntertheprimaryandsecondaryDNSserveraddresses.

Primary/Secondary WINS EntertheprimaryandsecondaryWINSserveraddresses.

Save Click Save to save and activate your settings.
