Section 8 - Viewing Status and Statistics

Path:Status>WirelessInformation>WDSGroupsStatus>WDSGroupAPStatus

TheWDSAPGroupStatuspagedisplaysdetailedinformationabouttheconguredAPsandlinksintheWDS

Group. From this page, you can also send a new password to group members.

Field Description

ID UniquenumberthatidentiestheWDSAPgroup.

Congured AP Count NumberofAPsconguredinthisWDSAPgroup.

Connected AP Count

NumberofAPsmanagedbythecontrollerthataremembersofthisWDSAP

Group.ThisnumberisthesumoftheConnectedRootAPsandConnected

SatelliteAPs.

Source AP Count

Number of Root APs currently being managed by the controllerthat are

membersofthisWDSAPGroup.

Destination AP Count

NumberofSatelliteAPscurrentlybeingmanagedbythecontrollerthatare

membersofthisWDSAPGroup.

Source Bridge AP MAC

MAC Address of the device elected as the Spanning Tree Root Bridge. If

spanning tree is disabled this value is 00:00:00:00:00:00.

Source Device Type

ThetypeofdeviceelectedastheSpanningTreeRootbridge:

• None(STPisdisabled)

• RootAP

• SatelliteAP

• ExternalDevice(STPRootisnotoneoftheAPs)

Cong WDS Link Count NumberofconguredbidirectionallinksintheWDSAPGroup.

Detect WDS Links Count

NumberofWDSlinksdetectedinthesystem.APsonbothsidesofthelink

must detect each other in order for the link to be counted.

WDS Group AP Status
