Section 8 - Viewing Status and Statistics

Viewing Statistic and Utilization

Path:Status>Dashboard

The wireless controller provides a dashboard that displays about the resources the system is using . The dashboard

page is organized into the following sections:

Section Description

Trac Overview Displaysachartoftracoverviewbyserviceforeachinterface.

Discovered APs

DisplaysachartofdiscoveredAPsbytheircurrentstatusasdetectedbythe

DWC-1000.

Bandwidth Usage

Displays bandwidth usage by network segment such as WLAN or LAN. The

dataisbrokenintobyapplicationsservicesuchasHTTP,HTTPS,DNS,SNMP,

and others.

WLAN Statistics

Displaysachartoftracoverviewbybandwidthandpacketinformationfor

WLANtraccapturedbyallofthemanagedAPscurrentlyassociated.

CPU Utilization

Percent of the CPU utilization currently consumed by the device.The CPU

utilization is broken down into specics such as all user space processes, such

asmanagementoperations,kernelspaceprocesses,andCPUidletimeorIO.

Memory Utilization

Displays a breakdown of memory usage by the amount used, free, cached,

andcurrentlyinthesystembuer.

Trac Information Displaysagridoftracstatisticsforeachinterface.
