D-Link DWC-1000 User Manual 284
Section 8 - Viewing Status and Statistics
Viewing VPN Sessions
Path:Status>NetworkInformation>ActiveVPNSessions
Note: This feature is only available when the DCS-1000-VPN license is activated.
TheActiveVPNSessions pagedisplaysthefollowinginformationabouttheactiveVPN sessionsthroughthe
wireless controller:
•PolicyName
•Endpoint
•TransferRate(KBandPackets)
•CongurationState
ClickthetaboftheVPNsessionyouwanttoview(IPSec,SSL,PPTP,orOpenVPN).
