D-Link DWC-1000 [318/368] Viewing wds link status

D-Link DWC-1000 User Manual 318

Section 8 - Viewing Status and Statistics

Path:Status>WirelessInformation>WDSGroupsStatus>WDSLinkStatus

TheWDSAPLinkStatuspagedisplayssummaryinformationaboutthelinkcongurationandlinkstateinaWDS

group.

Field Description

ID ThegroupnumberthatidentiestheconguredWDSAPgroup.

Source AP MAC TheMACaddressofoneend-pointoftheWDSlink.

Source AP Radio TheradionumberoftheWDSlinkendpointonthesourceAP.

Destination AP MAC TheMACaddressoftheSourceAPinthegroup.

Destination AP Radio TheradionumberoftheWDSlinkendpointonthedestinationAP.

Source AP End-Point

IndicateswhethertheAPspeciedbythedestinationMACdetectedtheAP

speciedbythesourceMAC.

Destination AP End-Point

Indicates whether the AP specied by the source MAC detected the AP

speciedbythedestinationMAC.

Aggregation Mode

WhenparallellinksaredenedbetweentwoAPs,thiseldindicateswhether

this link is part of the aggregation link pair.

Source AP STP

SpanningTreeStateofthelinkonthesourceAP,whichisoneofthefollowing:

• Disabled(STPisdisableorLinkisdown)

• Forwarding

• Learning

• Listening

• Blocking

Destination AP STP

SpanningTree State of the link on the destination AP, which is one of the

following:

• Disabled(STPisdisableorLinkisdown)

• Forwarding

• Learning

• Listening

• Blocking

Viewing WDS Link Status
