D-Link DWC-1000 User Manual 296

Section 8 - Viewing Status and Statistics

Field Description

Model Name ThemodelofthemanagedAP.

Firmware Version ThermwareversionofthemanagedAP.

MAC Address (*) Peer Managed

Ethernetaddressofthemanagedaccesspoint.Ifanasterisk(*)followsthe

MACaddress,theaccesspointismanagedbyapeercontroller.

IP Address NetworkIPaddressofthemanagedaccesspoint.

Location

An optional description of where the AP is physically located. Congured

throughtheAPmanagementsection.

Status

Currentmanagedstateoftheaccesspoint.Possiblevaluesare:

• Discovered=accesspointisdiscoveredbythewirelesscontroller,butnot

authenticated.

• Authenticated = accesspointhasbeen validated and authenticated(if

authenticationisenabled),butitisnotcongured.

• Managed = prolecongurationhasbeen appliedto the accesspoint

and the access point is operating in managed mode.

• Failed = wireless controllerlost contact with the access point. A failed

entryremainsintheManagedAPdatabase,unlessyouremoveit.Note

that a managed access point shows a failed status temporarily during a

reset.

If management connectivity is lost for a managed access point, both of

its radios are turned down and all clients associated with the access point

are disassociated. The radios resume operation when that access point is

managed again by a wireless controller.

Conguration Status

Shows whether the conguration prole applied to the managed access point

is successful or not.

Managed

Path:Status>WirelessInformation>AccessPoint>Managed

TheManagedAPListpageshowsdetailsaboutthemanagedaccesspoint.rightclickingamanagedaccesspoint

enables more options.
