D-Link DWC-1000 User Manual 238
Section 8 - Security
Mail Filtering
Path:Security>Firewall>ALGs>MailFiltering
1. Click Security > Firewall > ALGs > Mail Filtering tab.
2. Right-clickanentryandselecteitherEdit or Delete. To add a new mail ID, click Add New Mail Filter.
3. EnterasubjectandamailID.
4. Select to allow or block.
5. Click Save.
