D-Link DWC-1000 [18/368] Front panel

D-Link DWC-1000 User Manual 18

Section 1 - Product Overview

Front Panel

1 PowerLED

Asolidgreenlightindicatesagoodconnecttoapowersource.ThisLEDwillbe

orange during boot up.

2 USBPorts

TwoUniversalSerialBus(USB)2.0portsareprovidedforconnectingUSBashdrives,

harddrives,andprinters.AsolidLEDindicatestheUSBdeviceisattached.ThisLEDwill

blink during data transmission.

3 LANPorts(1-4)

FourGigabitEthernetportslabeled1through4letyouconnectEthernetdevicessuch

ascomputers,switches,andnetworkstorage(NAS)devices.EachporthasanActivity

LED(left)andLinkLED(right).

4 OptionPorts(1-2)

TwoGigabitEthernetportslabeledOptionletyouconnectthewirelesscontrollerto

a backbone (requires DWC-1000-VPN-LIC License Pack upgrade). Each port has an

ActivityLED(left)andLinkLED(right).

5 ConsolePort

The RJ-45 console cable lets you connect a PC to access the wireless controller’s

command-line interface.

Rear Panel

1 ResetButton Pressandholdfor10secondstoresettheswitchbacktothefactorydefaultsettings.

2 PowerPort Connect the supplied power cord to a power outlet or surge protector.

3 On/OSwitch Presstoturnthewirelesscontrolleronando.

52 3 4
