Field Description

MAC Address MACaddressoftheaccesspoint.

AP Mode

Select standalone, managed, or rogue. Selecting standalone will require you to ll out the elds

belowfromLocationtoExpectedWiredNetworkMode.

• Standalone

• Managed=Accesspointprolecongurationhasbeenappliedtotheaccesspointandthe

access point operating in managed mode.

• Rogue=Accesspointhasnottriedtocontactthewirelesscontrollerandtheaccesspoint’s

MACaddressisnotintheValidAPdatabase.

Location Optional eld to identify location of the access point being managed.

Expected SSID

IfAPMode=Standalone,theSSIDthattheaccesspointshouldbesettoisdisplayed.Thisisfor

reference only.

Expected Channel

IfAPMode=Standalone,thechanneltobeusedforwirelesscommunicationisdisplayed.This

is for reference only.

Expected WDS

Mode

IfAPMode=Standalone,theWDS(WirelessDistributedSystem)modetobeusedifyouintend

to use WDS. This is for reference only.

Expected Security

Mode

IfAPMode=Standalone,thesecuritymodetobeusedisdisplayed.Thisisforreferenceonly.

Expected Wired

Network Mode

IfAPMode=Standalone,selectwhetherwirednetworkingisgoingtobeallowed.Thisisfor

reference only.

Authentication IfAPMode=Managed,turnontorequireapasswordforauthentication.

Prole IfAPMode=Managed,selectaproletoapplyforAPconguration.

Radio

IfAPMode=Managed,thisisWirelessradiomodethattheaccesspointisusingisdisplayed.The

eldsbelowappearafteryouhaveselectedManagedAPMode.

Channel IfAPMode=Managed,thisisoperatingchannelfortheradio.

Power IfAPMode=Managed,thisispercentageofpowertousefortheradio.

4. Repeatsteps2and3foreachadditionalaccesspointyouwantthewirelesscontrollertomanage.
