D-Link DWC-1000 User Manual 188
Section 5 - Advanced Network Conguration
Field Description
Prole Name Enteranameforthisprole.
Priority
Select the priority of the prole. The choices are:
•Highest
•High
•Low
•Lowest
Maximum Bandwidth Enterthemaximumbandwidthvalueforthisprole.
Minimum Bandwidth Entertheminimumbandwidthvalueforthisprole.
Option Interface Select which Option interface to apply this prole to.
6. Go to Network > QoS > Option Trac Shaping.
7. Click Add New Trac Selector. Complete the elds on the next page and then click Save.
