ESIE06-05 Wiring Layout
Part 1 – System Outline 1–89
3
1
4
5
3.2.1 Notes
L1, L2, L3 : Main terminals
1-99 : Field wiring terminals
100-199 : Factory upwiring terminals
200- : Internal wiring terminals
U-Z : Main terminals in compressor switchbox
: Earth wiring
: Wire number 15
: Terminal number 15
: Field supply
: Option
: Not mounted in switchbox
: Wiring depending on model
: PCB
: Connection ** continues on page 12 column 2
!
: Pin against miswiring
: Several wiring possibilities
N-model : unit with no options included
Y1R, Y2R reversing valves are activated in cooling mode.
