ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–71
3
2
4
5
1
Superheat Control These screens allow modification of the superheat control.
Remark: Do not change these parameters because they have a direct influence on the superheat
control.
EEV Feed Forward
Control Ambient
Setpoints
Settings:
_
TRANSIENT TIME:300s
KP COOL DRY:01.6
KP HEAT DRY:02.2
EEV CONTROL
_
TIP COOL DRY:002s
TIP HEAT DRY:003s
EEV CONTROL
_
KP COOL WET:01.8
KP HEAT WET:02.6
EEV CONTROL
_
KP COOL WET:002s
KP HEAT WET:003s
EEV CONTROL
_
KP COOL NORMAL:03.0
KP HEAT NORMAL:03.0
EEV CONTROL
_
KP COOL NORMAL:020s
KP HEAT NORMAL:015s
EEV CONTROL
FF CONTROL TIME : If the compressor load changes during thermostat control, the
controller will change the EV opening after the “FF CONTROL
TIME”.
COOL AMB. CONST : Ambient setpoint in cooling mode for the feed forward control when
the compressor load goes up or down.
HEAT AMB. CONST : Ambient setpoint in heating mode for the feed forward control
when the compressor load goes up or down.
_
FF CONTROL TIME:03s
COOL AMB.CONST:005.0 °C
EEV CONTROL
HEAT AMB.CONST:005.0 °C
