Procedure for Software Upload ESIE06-05
3–40 Part 3 – Troubleshooting
3
1
3
4
5
4.4 Installation of PCASOflash Software
Only needed if software is not yet present on PC.
Remark: Only possible to install if user has administrator rights.
Necessary files: PCAS0flash0xx.msi. (xx depending on version)
■ To install PCASOflash software: execute PCAS0flash0xx.msi.
Select Each time Next when required.
Remark: When “Error 1913” message is shown, select OK (this has no influence on the good
functioning of the software)
■ To install a newer PCASOflash software, it is required to first remove the existing PCASOflash
software as follows: execute PCAS0flash0xx.msi.
Select “Remove PCASO flash” and push next.
