General Outline ESIE06-05
1–22 Part 1 – System Outline
3
11
4
5
1.15 Electrical Specifications for options: EWAQ180-210DAYN
Electrical
specifications
The table below contains the electrical specifications for the options of the EWAQ180-210 DAYN.
Electrical specifications options
OPSP
Units EWAQ180DAYN* EWAQ210DAYN*
Std Pump Starting method Direct On-Line
Power W 4kW 4kW
Maximum Running current A 8 8
Starting current A 98 98
OPHP
Units EWAQ180DAYN* EWAQ210DAYN*
High Esp Pump Starting method Direct On-Line
Power W 7,5kW 7,5kW
Maximum Running current A 15,2 15,2
Starting current A 169 169
OP10
Units EWAQ180DAYN* EWAQ210DAYN*
Heater Tape Supply Voltage V 230+/-10%
Recommended fuses A 2x 10A
Power standard model 1 x 300W 1 x 300W
Power model with pump 2 x 300W 2 x 300W
Power model with pump and buffer
tank
2 x 300W + 1 x 150W 2 x 300W + 1 x 150W
