ESIE06-05 The Digital Controller For Multiscroll Chillers

Part 2 – Functional Description 2–83

Changeable

Analogue Inputs

These screens allow modification of the analogue inputs.

Settings:

Changeable

Analogue Output

This screen allows modification of the analogue output.

Settings:

AI2 : To set the analogue input 2

AI2 TYPE : To set the type of the analogue input 2

AI3 : To set the analogue input 3

AI3 TYPE : To set the type of the analogue input 3

AI4 : To set the analogue input 4

AI4 TYPE : To set the type of the analogue input 4

When programming this analogue input, check the field wiring to see if the input has been installed

correctly.

_ CHANG. INP/OUTPUTS

AI2:NONE

AI2 TYPE:0-20mA

AI3:NONE

_ CHANG. INP/OUTPUTS

AI3 TYPE:0-20mA

AI4:NONE

AI4 TYPE:0-20mA

AO1 : To set the analogue output 1

AO1 TYPE : To set the type of the analogue output 1

Possible settings for the analogue output.

■ None

■ Unit capacity

_ CHANG. INP/OUTPUTS

AO1:NONE

AO1 TYPE:0-20mA
