ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–23
3
2
4
5
1
Possible compressor status:
• SAFETY ACT: one of the circuit safety devices is activated.
• FREEZEUP DIS: the compressor is disabled by the freeze-up disable function.
• FREEZEUP PR: the freeze-up prevention is active.
• DEFROST BUSY: defrost is active on this circuit.
• COMP PR: the compressor protection function is active.
• HP SETBACK: the high pressure setback is active.
• MIN.RUN.TIM.: the minimum running time of the compressor is active.
• LIMIT: the compressor is limited by the limitation function.
• STANDBY DICN: when in a DICN configuration, the unit is in standby mode because there is suf-
ficient current capacity to maintain set point.
• UNIT OFF: the unit is switched off.
• AREC INLET: the compressor will not start up when the inlet water temperature has not risen
enough compared to the previous switch off of the compressor.
• FREE COOLING: the free cooling mode is active.
• TIMER BUSY: the actual value of one of the compressor timers is not zero.
• PUMPLEAD TIM: the compressor will wait to start up for as long as the pump lead timer is count-
ing down.
Screen 17 This screen shows the actual operational information about the current (Ampère) and voltage of the
unit.
This screen is only visible when the A-meter, V-meter (option OP57) is installed.
EXTRA READOUT
CURRENT:055A
VOLTAGE:230V
_
