The Digital Controller For Multiscroll Chillers ESIE06-05
2–62 Part 2 – Functional Description
3
1
2
4
5
2.15.1 Thermostat
Thermostat
settings for V2.1
This screen allows modification of the thermostat settings for software version V2.1.
Settings:
Thermostat
settings for V2.2 or
higher
This screen allows modification of the thermostat settings for software version V2.2.
Settings:
A:Step difference value, used for the thermostat function
C:Step length value, used for the thermostat function
RESTART COND : Restart condition parameter, used to restart the unit after a
forced thermo off in outlet mode.
Possible settings:
A x 1
A x 2
A x 3
A x 4
Remark: The restart condition parameter A in this function
is the same as the programmed step difference value A.
_
STEPLENGTH
A:04.0 °C
RESTART COND.:Ax2
C:00.4 °C
THERMOSTAT
A:Step difference value, used for the thermostat function
C:Step length value, used for the thermostat function
RESTART COND : Restart condition parameter (default 4°C), used to restart
the unit after a normal thermo off in outlet mode.
Restart condition value x 2: Restart condition parameter
(default 2), used to restart the unit after a forced thermo off
in outlet mode.
_
STEPLENGTH
A:04.0 °C
RESTART COND.:4.0°C x2
C:00.4 °C
THERMOSTAT
