The Digital Controller For Multiscroll Chillers ESIE06-05
2–20 Part 2 – Functional Description
3
1
2
4
5
These screens show the actual operational information about the refrigerant temperature and the coil
temperature.
Screen 11
Screen 12 This screen is only visible if the unit has 2 circuits.
Remark: Coil sensors are only present on EWYQ units.
C1 TEMP.READOUT
C1 REFR:000.0 °C
C11 COIL:000.0 °C
_
C12 COIL:000.0 °C
Display Description
C1 TEMP. READOUT Temperature readout of circuit 1
C2 TEMP. READOUT Temperature readout of circuit 2
C1 REFR. Refrigerant temperature of circuit 1
C2 REFR. Refrigerant temperature of circuit 2
C11 COIL Temperature of coil 1 of circuit 1
C12 COIL Temperature of coil 2 of circuit 1
C21 Temperature of coil 1 of circuit 2
C22 Temperature of coil 2 of circuit 2
C2 TEMP.READOUT
C2 REFR:000.0 °C
C21 COIL:000.0 °C
_
C22 COIL:000.0 °C
