Daikin EWYQ230DAYN [187/524] Fieldwiring do changeable do
![Daikin EWAQ260DAYN [187/524] Fieldwiring do changeable do](/views2/1657857/page187/bgbb.png)
ESIE06-05 Wiring Layout
Part 1 – System Outline 1–175
3
1
4
5
3.4.18 Fieldwiring DO, changeable DO
Operation
M11C
External
Power
supply
(ex 24VAC
or 230VAC)
Operation
M12C
External
Power
supply
(ex 24VAC
or 230VAC)
AC15: max.3A-230V
Alarm NO
Default
Safety active = contact closed
No power = contact open
No safety = contact open
9
Changeable DO1
(Default: Alarm,
NO contact 8-9)
External
Power
supply
(ex 24VAC
or 230VAC)
Alarm NC
Software selection necessary
Safety active = contact closed
No power = contact closed
No safety = contact open
9
Changeable DO: Maximum load: 2A-230VAC, Minimum load: 10mA-5VDC
External
Power
supply
(ex 24VAC
or 230VAC)
Changeable DO2
(Default:
Gen. operation)
External
Power
supply
(ex 24VAC
or 230VAC)
13
14
K11M
3
3
4
4
H11P
13
14
K12M
5
5
6
6
H12P
7
7
A11P
X22A:5
K12R
X22A:1
8
8
X22A:3
9
9
H1P
7
H1P
8 9
A11P
X24A:2
K14R
X24A:1
10
10
11
11
H2P
