ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–27
3
2
4
5
1
2.8.1 Thermostat settings
Thermostat This screen allows modification of the control settings.
Possible settings MODE:
Remark: The load up and load down time changes according to the selected operation mode.
Manual Setting This screen allows modification of the manual control settings.
This screen is only visible when MANUAL is selected as thermostat mode (see THERMOSTAT
screen)
Possible settings C11 / C12 / C21 / C22:
■ INL WATER:
inlet water control
LOAD UP: 180s minimum load up time between 2 compressor starts
DOWN : 30 s minimum load down time between 2 compressor stops
■ OUTL WATER: outlet water control
LOAD UP: 30s minimum load up time between 2 compressor starts
DOWN: 15s minimum load down time between 2 compressor stops
■ MANUAL CONTROL: manual control (no thermostat control active)
THERMOSTAT
MODE:INL WATER
LOADUP:180s-DWN:030s
_v
ON : compressor ON
OFF : compressor OFF
MANUAL SETTINGS
C11:OFF
C21:OFF
_^
F1*:OFF F2*:OFF
C22:OFF
C12:OFF
