ESIE06-05 Wiring Layout
Part 1 – System Outline 1–147
3
1
4
5
3.3.22 Fieldwiring DO, changeable DO
Operation
M11C
External
Power
supply
(ex 24VAC
or 230VAC)
Operation
M12C
External
Power
supply
(ex 24VAC
or 230VAC)
Operation
M21C
External
Power
supply
(ex 24VAC
or 230VAC)
AC15: max.3A-230V
Operation
M22C
External
Power
supply
(ex 24VAC
or 230VAC)
Alarm NO
Default
Safety active = contact closed
No power = contact open
No safety = contact open
9
Changeable DO1
(Default: Alarm,
NO contact 8-9)
External
Power
supply
(ex 24VAC
or 230VAC)
Alarm NC
Software selection necessary
Safety active = contact closed
No power = contact closed
No safety = contact open
9
Changeable DO: Maximum load: 2A-230VAC, Minimum load: 10mA-5VDC
External
Power
supply
(ex 24VAC
or 230VAC)
Changeable DO2
(Default:
Gen. operation)
External
Power
supply
(ex 24VAC
or 230VAC)
13
14
K11M
3
3
4
4
H11P
13
14
K12M
5
5
6
6
H12P
13
14
K21M
22
22
23
23
H21P
13
14
K22M
24
24
25
25
H22P
7
7
A11P
X22A:5
K12R
X22A:1
8
8
X22A:3
9
9
H1P
7
H1P
8 9
A11P
X24A:2
K14R
X24A:1
10
10
11
11
H2P
