![Daikin EWAQ080DAYN [269/524] Timers menu](/views2/1657857/page269/bg10d.png)
ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–43
3
2
4
5
1
2.9 Timers menu
Software Timers Using this menu, the actual software timers can be read out. This menu displays three screens.
General Timers This screen shows the actual value of the general timers:
Compressor Timers These screens show the actual value of the compressor timers.
Display Description
LOADUP ■ LOADUP: starts counting when a thermostat step change has occurred.
During the countdown, the unit is not able to go to a higher thermostat step.
DWN
■ LOADDOWN: starts counting when a thermostat step change has occurred.
During the countdown, the unit is not able to go to a lower thermostat step.
PUMPLEAD
■ FLOWSTART-20sec: counts down when the water flow through the
evaporator is continuous and the unit is in standby. During the countdown,
the unit cannot start up.
PUMPLAG
■ Counts down after the unit is switched off. During the pump lag time (60s)
the pump will keep running after the chiller has stopped. (appears when
PUMPLEAD TIME = 0)
FLOWSTOP
■ FLOWSTOP-5 sec: starts counting when the water flow through the
evaporator stops after the flowstart timer has reached zero. If the water flow
has not restarted during the countdown, the unit will shut down.
_v
LOADUP:000s-DWN:000s
PUMPLEAD
FLOWSTOP
GENERAL TIMERS
:00s
:000s
_
GRD11:000s
AREC11:000s
M.RT11:000s
COMPRESSOR TIMERS
12:000s
12:000s
12:000s
_^
GRD21:000s
AREC21:000s
M.RT21:000s
COMPRESSOR TIMERS
22:000s
22:000s
22:000s
