The Digital Controller For Multiscroll Chillers ESIE06-05
2–86 Part 2 – Functional Description
3
1
2
4
5
Serial
Communication
Parameters
This screen allows modification of the serial communication parameters.
Parameters for the RS232 communication:
■ Not used in multiple scroll units.
BNS
Communication
Parameters
This screen allows modification of the communication PCB parameters (BMS settings)
Settings:
_
RS232:NONE
COMMUNICATION PCB
BR:19200bps
RS485 : ■ NONE: communication disabled
■ MODBUS : MODBUS communication enabled
ADDR : Address of the unit in the BMS system
BR : Indicates the speed of communication
(19200/9600/4800/2400/1200)
PARITY :
■ NONE (2 stop bit)
■ EVEN (1stop bit)
■ ODD (1 stop bit)
_
RS485:NONE
COMMUNICATION PCB
BR:19200bps
PARITY:EVEN (1STOPb)
ADDR:01
