ESIE06-05 The Digital Controller For Multiscroll Chillers

Part 2 – Functional Description 2–21

These screens show the actual operational information about the high and low pressure and the fan

output.

Screen 13

Screen 14 This screen is only visible if the unit has 2 circuits.

C1 ACT. PRESSURES

HP1:019.0b = 050.8 °C

LP1:004.4b = -05.2 °C

FAN1:OFF

Display Description

C1 ACT. PRESSURES actual pressures of circuit 1

C2 ACT. PRESSURES actual pressures of circuit 2

HP1: b = °C actual high pressure and corresponding temperature

LP1: b = °C actual low pressure and corresponding temperature

HP2: b = °C actual high pressure and corresponding temperature

LP2: b = °C actual low pressure and corresponding temperature

FAN1/FAN2 actual fan output

OFF : OFF

L : low speed

M : medium speed

H : high speed

000% : percentage of inverter fan out-

put (only with OPIF)

LOW NOISE : N/Y Indication if low noise mode is active at the moment (only with

OPIF)

C2 ACT. PRESSURES

HP2:019.0b = 050.8 °C

LP2:004.4b = -05.2 °C

FAN2:OFF
