ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–39
3
2
4
5
1
Settings:
When a password is needed to switch the unit ON or OFF, the following screen will be displayed while
pushing the ON/OFF button.
When the password is entered, the unit will switch ON/ OFF.
This screen allows modification of the advanced main menu, logout timer and buzzer settings.
Settings:
PASSWORD NEEDED FOR:
SETPOINT MENU : Y: User password is needed to enter the setpoint menu
N: no password is needed to enter the setpoint menu
UNIT ON/ OFF : Y: user password is needed to switch the unit ON or OFF
N: no password is needed to switch the unit ON or OFF
SWITCH UNIT ON/OFF
ENTER PASSWORD
PASSWORD:0000
TO SWITCH UNIT ON
MAIN MENU : set to GRAPHIC to let the main menu show the graphical
symbols or to TEXT to let the main menu show the names
of the menus.
_
MAIN MENU:GRAPHIC
LOGOUT TIMER:05min
BUZZER IF SAFETY:YES
ADVANCED
