ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–67
3
2
4
5
1
Fan Control Timers This screen allows modification of the fan timers.
Settings:
Remark: Different default timers are used for ON/OFF and inverter fans
Fan inverter
Frequency
This screen allows modification of the fan inverter frequency for each fan step.
Settings:
COMPRESSION
RATIO
: Used for pressure difference surveillance control
LOADUP TIM : Load up time, minimum time between 2 fan up steps
LOADDOWN TIM : Load down time, minimum between 2 fan down steps
LOADUP TIME : ON/OFF fans: 90s
Inv. fans: 15s
LOADDOWN TIME : ON/OFF fans: 180s
Inv. fans: 90s
_^
COMPRESSION RATIO:1.6
LOADUP TIM:0015s
LOADDOWN TIM:0090s
FAN CONTROL
ST1 : Frequency used for inverter fan step 1
ST2 : Frequency used for inverter fan step 2
ST3 : Frequency used for inverter fan step 3
ST4 : Frequency used for inverter fan step 4
ST4:50HZ
ST2:30HZ
ST3:45HZ
FAN INV FREQ
ST1:20HZ
