ESIE06-05 The Digital Controller For Multiscroll Chillers
Part 2 – Functional Description 2–53
3
2
4
5
1
Changeable Digital
Inputs/Outputs
This screen shows the status of the digital inputs and outputs.
Changeable Digital
Outputs
This screen shows the status of the digital outputs.
Display Description
DI4 Changeable digital input 4 + status of input
DO1 Changeable digital output 1 + status of output
DO2 Changeable digital output 2 + status of output
_ CHANG.
DI4 NONE
DO1 SAFETY+W.(NO)
DO2 GEN.OPERATION
DIG. INPUTS
:0
:0
Display Description
DO3 Changeable digital output 3 + status of output
DO4 Changeable digital output 4 + status of output
DO5 Changeable digital output 5 + status of output
_ CHANG.
DO3 NONE (OPEN)
DO4 NONE (OPEN)
DO5 NONE (OPEN)
INP/OUTPUTS
