The Digital Controller For Multiscroll Chillers ESIE06-05
2–40 Part 2 – Functional Description
3
1
2
4
5
This screen allows modification of the advanced backlight and graphic readout settings.
Settings:
■ LOGOUT TIMER : Set the time for automatic log out, between 01 and 30
minutes.
■ BUZZER IF SAFETY : To activate or deactivate the buzzer sound when an error
occurs.
y
z
a
b
d
r
u
e t
q
Main menu Graphic
>
USERSETTINGS MENU
HISTORY MENU
READOUT MENU
SETPOINTS MENU
INFO MENU
I/O STATUS MENU
LOGIN/LOGOUT MENU
NETWORK MENU
COOL/HEAT MENU
TIMERS MENU
Main menu Text
BACKLIGHT TIME : to define the time (between 01 and 30 minutes) the light of
the controller display will stay on after the last manipulation
of the controller buttons.
GRAPHIC READOUT : to define if the graphical representation of the first screen of
the read out menu is present or not.
ADVANCED
BACKLIGHT TIME:05min
GRAPHIC READOUT:YES
_^
