The Digital Controller For Multiscroll Chillers ESIE06-05
2–12 Part 2 – Functional Description
3
1
2
4
5
2.3 Start/Stop, Cool/Heat and Temperature settings
Power on ■ The initialization takes 20 seconds.
■ The controller automatically goes to the menu overview.
Remote start/stop The procedure to start or stop the unit depends on the settings of the remote start/stop.
Remark: The remote start/stop is field supply.
How to start or stop
How to cool or heat To change from cooling to heating (or visa versa) you have to enter the Cooling/Heating menu through
the main menu or a remote cool/heat signal can be used.
Remark: The remote cool/heat is field supply.
Temperature
Setting
To adjust the inlet or outlet water temperature, go to the Set Points menu through the main menu.
Local key Remote Switch Unit
LED
ON ON ON ON
ON OFF OFF Flashing
OFF ON OFF OFF
OFFOFFOFFOFF
