The Digital Controller For Multiscroll Chillers ESIE06-05
2–18 Part 2 – Functional Description
3
1
2
4
5
These screens show the actual operational information about the EEV control. They are only visible
when they are enabled in the service / EEV menu. The screens are only visible if the unit has 2 circuits.
Screen 6
Screen 7
Screen 8
:
C2 TEMP.READOUT
SUCTION C2:007.4 °C
SUPERHEAT C2:007.3 °C
EEV PULS C2:0000PLS
C2 TEMP.READOUT
SUCTION H21:007.4 °C
SUPERHEAT H21:007.3 °C
EEV PULS H21:0000PLS
Display Description
C2 TEMP. READOUT operational information EEV control of circuit 2
SUCTION C2 suction temp. in cooling mode of circuit 2
SUCTION H21 suction temp. in heating mode of compressor 1 of circuit 2
SUCTION H22 suction temp. in heating mode of compressor 2 of circuit 2
SUPERHEAT C2 actual superheat in cooling mode of circuit 2
SUPERHEAT H21 actual superheat in heating mode of coil 1 of circuit 2
SUPERHEAT H22 actual superheat in heating mode of coil 2 of circuit 2
EEV PULS C2 actual electronic expansion valve opening in cooling
mode
EEV PULS H 21 actual electronic expansion valve opening in heating
mode of expansion valve of coil 1
EEV PULS H22 actual electronic expansion valve opening in heating
mode of expansion valve of coil 2
C2 TEMP.READOUT
SUCTION H22:007.4 °C
SUPERHEAT H22:007.3 °C
EEV PULS H22:0000PLS
